ARRILITE 750W PLUS

- alette
- 2 veli metallici
The ARRILITE 750 Plus is a new and improved incarnation of ARRI’s traditional, open-faced light, the ARRILITE 800/1000. By optimizing the ARRIMAX reflector for usage with an HPL* 750 W lamp, the ARRILITE 750 Plus offers 21 % higher light efficiency than the previous ARRILITE 800 W, while the ARRIMAX optical system improves distribution of the light. A detachable and fully rotatable accessory holder accommodates scrims and barndoors, and incorporates fittings that permit the Chimera Video Pro Plus S to be fitted directly, without an additional speedring.

The one-arm stirrup allows for plenty of pan-and-tilt options and a heat-proof handle at the rear of the lamphead enables easy maneuvering. No tools are required for changing bulbs as the housing consists simply of two detachable parts that open and close through bayonet cap locks. The smaller and lighter aluminum housing of the ARRILITE 750 Plus makes it an ideal lamphead for lighting kits and therefore also suitable for electronic newsgathering, field production and fast turnaround location use.
MAX Technology reflector enables better light distribution
Compatible with 375 W, 573 W and 750 W HPL* bulbs
21 % increase in light efficiency compared to the previous ARRILITE 800 model
New accessory holder permits the Chimera Video Pro Plus to be fitted directly,
without an additional speedring
One-arm stirrup allows a variety of pan-and-tilt possibilities
No tools required to change the bulb
Compact design; smaller and lighter housing than the previous ARRILITE 800 model
Aluminum housing enables heat dissipation
Heat-proof handle at rear of housing enables easy maneuvering
Compatible with ARRI 650 Plus accessories
Mains PlugSchuko, Bare Ends
Lamphead TypeOpen Face with parabolic facetted reflector, 750 W
ReflectorMAX reflector made of high purity aluminium
Lamp TypeHPL** 750 W, 575 W, 375 W; GKV*** 600 W, FKR 650 W, HX 800 W
Power Consumption800 W, 750 W, 650 W, 600 W, 575 W, 375 W
Voltage Range100 to 240 V
Lamp BaseG9.5
Dimmingyes, 0 to 100 % via external dimming system
Correlated Color Temperature3,200 K
Beam Angle21° to 73°
Weight in kg net*approx. 2 kg
Weight in kg packed*approx. 3 kg
Weight in lbs. net*approx. 4 lbs
Weight in lbs. Packed*approx. 7 lbs
Measurements (HxWxL) incl. Pin in mm*-
Measurements (HxWxL) excl. Pin in mm*226 x 230 x 224 mm
Measurements (HxWxL) incl. Pin in inch*-
Measurements (HxWxL) excl. Pin in inch*8.9 x 9.1 x 8.8"
Measurements (HxWxL) Packed size in mm*260 x 230 x 290 mm
Measurements (HxWxL) Packed size in inch*10.2 x 9.1 x 11.4"
Lens / UV-Protection Glass Diameter in mm150 mm
Lens Diameter in inch5.9"
Accessory Diameter in mm168 mm
Accessory Diameter in inch6.6" (Scrim)
Barndoor in mm168 mm
Barndoor in inch6.6"
MountingSocket 16 mm / 5/8" (0.6")
Housing ColorBlue
Protection Class / IP RatingI / IP20
CertificationsCE, CB, ENEC, cNRTLus
