ARRILITE 2000W PLUS

- alette
- 2 veli metallici
The continuing popularity of the ARRILITE 2000 has inspired ARRI’s lighting team to undertake a complete redesign and update of this traditional, open-faced lamphead. Incorporating a range of innovative features, the new ARRILITE 2000 Plus meets the exacting production demands of today’s film and television industries. By utilizing the ARRIMAX reflector and optical system, light efficiency is increased and light distribution improved.

The aluminum housing is more compact and about 400 g lighter than the previous model, while disc brake technology borrowed from the ARRI True Blue range holds the ARRILITE 2000 Plus steady even with heavy accessories attached. In order to change bulbs, the door opens in a similar way to the ARRI M18; no screws have to be removed and no tools of any kind are needed. Like the ARRILITE 750 Plus, the ARRILITE 2000 Plus features an improved focus mechanism and heat-proof handle at the rear of the housing that facilitates easy maneuvering.
MAX Technology reflector enables higher light efficiency and better light distribution
No tools required to change the bulb
400 g lighter and more compact housing than the previous ARRILITE 2000 model
Aluminum housing enables heat dissipation
True Blue disc brake technology
Heat-proof handle at rear of housing enables easy maneuvering
Mains PlugSchuko, Bare Ends
Lamphead TypeOpen Face with parabolic facetted reflector, 2,000 W
ReflectorMAX reflector made of high purity aluminium
Lamp TypeFEX 2,000 W/230 V, FEY 2,000 W/120V
Power Consumption2,000 W
Voltage Range220 to 240 V
Lamp BaseRX7s
Dimmingyes, 0 to 100 % via external dimming system
Correlated Color Temperature3,200 K
Beam Angle24° to 63°
Weight in kg net*approx. 3 kg
Weight in kg packed*approx. 6 kg
Weight in lbs. net*approx. 7 lbs
Weight in lbs. Packed*approx. 12 lbs
Measurements (HxWxL) incl. Pin in mm*-
Measurements (HxWxL) excl. Pin in mm*317 x 355 x 241 mm
Measurements (HxWxL) incl. Pin in inch*-
Measurements (HxWxL) excl. Pin in inch*12.5 x 14.0 x 9.5"
Measurements (HxWxL) Packed size in mm*375 x 345 x 320 mm
Measurements (HxWxL) Packed size in inch*14.8 x 13.6 x 12.6"
Lens / UV-Protection Glass Diameter in mm215 mm
Lens Diameter in inch8.5"
Accessory Diameter in mm254 mm
Accessory Diameter in inch10.0" (Scrim)
Barndoor in mm254 mm
Barndoor in inch10.0"
MountingSocket 16 mm / 5/8" (0.6")
Housing ColorBlue
Protection Class / IP RatingI / IP20
CertificationsCE, CB, ENEC, cNRTLus
